Machine controls and connections
The main controls and connections are located on the side and rear of the machine.
Machine controls and connections
|
1 |
HMI device |
|
2 |
Emergency stop (E-stop) on machine Emergency stop (E-stop) on remote hand-held device |
|
3 |
USB connector |
|
4 |
Over-ride switch |
|
5 |
Main power switch |
|
6 |
120V AC power receptacle (L5-20) |
|
7 |
Emergency hydraulic pressure release button |
